easySpiral pro
Automatic plater
Traceability guaranteed
easySpiral Pro is an automatic plater of Petri dishes. It allows plating of a sample of 100 to 1x107 CFU/mL on one Petri dish, without prior dilution. Traceability is ensured and volumes are programmable via USB connection.
- Traceability and programmable volumes
- Plating modes: exponential, constant, circle
- Counting range: from 100 to 1x107 CFU/mL
- Plating cycle time: 25 seconds
The Spiral method
With the Spiral method, increase your analysis capabilities: without intermediate dilutions, perform standardized automatic plating with a counting range from 100 to 1 x 107 CFU/mL on 1 single Petri dish!
One touch plating
Plate easily and quickly your 90 and 150 mm Petri dishes. Choose from 3 plating modes: exponential, constant and circle.
Exponential mode
The exponential mode is a plating in surface with a decreasing surface concentration. Plate 50 µL or 100 µL volume. Obtain a countable Petri dish from 300 to 1.3 x 105 CFU/mL
Constant mode
The constant mode is a homogenous surface deposition plating. Plate 50 µL, 100 µL, 200 µL or program a customizable volume. Colony counting is then easy because there are no colonies on the edges of the Petri dish.
High speed automation
The fast rotating arm adapts itself to all types of agar without risks of ploughing. It makes it possible to obtain a plating in 25 seconds (disinfection + sample intake + plating).
Traceability ensured with dataLink
All the sample data, from plating (volume, dilution, plating mode ...) to automatic colony counting (lighting settings) are set on the Datamatrix label.
Applications
easySpiral Pro platers are used for all types of microbiological analyses in the food, pharmaceutical, cosmetic and public research institutes ...
